Product Description
Model | 1325 Pro ATC Cycle |
Working table size | 1300*2500*250mm |
Auto loading & unloading table | 1300*2500mm |
Transmission | Gear & ball screw |
Z axis movement | 25mm ball screw |
X axis & Y axis movement | CSK 30mm linear guide |
Electrical | Schneider |
Spindle | 9KW 24000rpm air cooling |
Drive X & Y axis | Delta 1000w servo motor |
Drive Z axis | Delta 100W servo motor with break |
Inverter | 11KW Delta Brand |
Table | 6 zone vacuum table |
Vacuum pump | 7.5 KW oilless |
Control system | Weihong NC 65C |
Tool length sensor | Include |
Position cylinder | X axis 3 pcs, Y axis 4 pcs |
Reducer | Gear box with shimpo reducer |
Sensor Safety Barrier | Include |
Vacuum pump star-delta start | Include |
Machine Size | 3100*2300*2500mm |
Machine Weight | 3000 KGS |
Main function
Spindle:
such as 6KW or 9KW power spindle automatic tool changer, speed range 5000-24000 RPM.
Automatic tool changer system:
8, 12, 16 positions linear or disk automatic tool changer functions to enhance productivity.
Multi-zone vacuum adsorption table:
optional double-stage air pump or dry vacuum pump can help to better fix the material.
Control system:
Adopt industrial grade Weihong controller to ensure precision and reliability.
Drive:
Servo motor drive of different brands is optional.
