Machine Details
 |  |  |  |  |  |  |  |  |  |
Specification
Model | EB-6 |
Work piece Min. length | 120mm |
Work piece Min. width | 120mm |
Work piece thickness | 10-55mm |
Edge tape height | 12—60mm |
Edge tape thickness | 0.4—3mm |
Feeding speed | 13—18m/min |
Working pressure | 0.6—0.8Mpa |
Total power | 13.4KW |
Machine size | 5300*700*1500mm |
Machine weight | 1350 Kgs |
Details
 |  |  |
 |  |  |
 |  |  |
Main Use
Applicable to all cabinets closets, office furniture, wooden doors edge laminating different materials decorative edge banding strip.
Functions can be selected from manual curved straight line edge banding, automatic straight line edge banding: optional functions are --- pre-milling, edge banding, end cutting, trimming, corner rounding, scraping, buffering and so on.
Conventional EVA hot melt adhesive can be used, PUR adhesive machine can also be added with PUR adhesive, as well as the most advanced laser edge banding device.
Can be equipped with side drilling system to drill installation holes after edge banding, reducing the use of separate side hole equipment and the use of manual labor, more effective to improve work efficiency.
