Product Description
Model | 1325 Pro |
Working table size | 1300*2500*200mm |
Transmission | Gear & ball screw |
Z axis movement | 25mm ball screw |
X axis & Y axis movement | 25mm linear guide |
Electrical | Chint |
Spindle | 6KW 18000rpm air cooling |
Drive X & Y axis | Leadshine 1500w servo motor |
Drive Z axis | Leadshine 1500W servo motor with break |
Inverter | 7.5KW Fulin Brand |
Table | 6 zone vacuum table |
Vacuum pump | 7.5 KW Air cooling |
Control system | Weihong NC 60A |
Tool length sensor | Include |
Position cylinder | X axis 2 pcs, Y axis 3 pcs |
Reducer | Gear box with shimpo reducer |
Machine Size | 3100*2300*2500mm |
Machine Weight | 1800 KGS |
Main function
Spindle:
such as 6KW or 9KW power spindle automatic tool changer, speed range 5000-24000 RPM.
Automatic tool changer system:
8, 12, 16 positions linear or disk automatic tool changer functions to enhance productivity.
Multi-zone vacuum adsorption table:
optional double-stage air pump or dry vacuum pump can help to better fix the material.
Control system:
Adopt industrial grade Weihong controller to ensure precision and reliability.
Drive:
Servo motor drive of different brands is optional.
